Quick Details

• Use:Truck Trailer

• Type:Semi-Trailer

• Material:Steel

• Certification:ISO9001

• Size:9000*2500*3836mm

• OEM No:CIMC trailer

• Max Payload:40T

• Place of Origin:Shandong, China (Mainland), Shandong, China

• Brand Name:CIMC, CIMC

• Model Number:ZJV9400GFLRGB

Packaging & Deliver

RUNNING GEAR :

Suspension : Mechanical suspension within three axles and 10pcs 90mm* 13mm

(width*thickness) springs.

Axle : 1 50x150 square axle with 13 tons capacity. Brake: S420x180, Wheel fitting

10xM22x1.5/ PCD335/281. Type: FUWA. Made in China.

Brake : Dual line pneumatic brake system. Type 30/30 spring brake system on one axle.

ISO type air coupling at front of the semi-trailer. With Chinese ABS.

Wheel : 9.0-22.5, 13pcs. Made in china.

Tire : 12.00R22.5 steel Disc, 13pcs. Chinese famous brand. choose by the factory.

King Pin : JOST 2", the king pin is bolted on the skid plate.

LANDING LEG:

Jost two speed manual operated from one side. Having lifting capacity of 24 ton, and static

capacity of 50 ton dead load. JOST

ELECTRICAL:

Voltage : 24 Volt.

Receptacle : 7 pole plug placed at front in accordance to ISO, norms NO.1185.

Light :

Front marker lamp : white

Side marker lamp : amber

Rear lamp : red

Turn signal lamp : amber

STRUCTURAL WEIGHT RATTING:

Tare Weight : 8,800kg approx

Payload : 40,000kg

G.V.W.R. : 48,800kg approx

TANK SPECIFICATION:

Capacity : 30000 plus 5%. Vapor Volume

Compartments : One compartments.

Tank material : Carbon steel Q345A material, the thickness of the shell is 4mm-nominal.

Dish ends material : Carbon steel Q345A material, the thickness of the shell is 4.5mm-nominal.

Test pressure designed : 0.2Mpa.

Discharging line: 5’’ butterfly valve and 4’’ steel pipe.

Discharging hose: 7 meters long with 4’’ female quickly coupling.

Manhole : 2pcs

TANK ACCESSORIES AND FITTINGS :

4’’ male quickly coupler-1pc

PNEUMATIC SYSTEM:

Diesel Engine: Kefa 4102 made in China

Air Compressor: Suzhou 10/2 made in China
