Quick Details

·Use:Other Trailers

·Place of Origin:Shandong, China (Mainland)

·Brand Name:CIMC

Packaging & Delivery

Packaging Details:In bulk or by container

Specifications

1.High tensile steel
2.Less weight,more load
3.Lower price,high quality.
4.Well design to save the freight

Specifications:
1) Dimensions and weight:
A) Nominal dimensions (L x W x H):12,500 x 2,500 x 1,500mm
B) King pin height: 1,300mm
C) King pin setting: 1, 000mm from rear face of front bolster
D) Max. Payload: 40,000kg / 45,000kg e) Tare weight: 6, 500kg± 2% / 7, 200kg±2%
2) Running system:
A) Suspension system: Leaf spring or airbag suspension
B) Axle: Various axles like BPW, YORK,FUWA ect. With various bearings
C) Tyre: Various brands of bias tyres or radial tyres
D) King pin: Forged steel,2"or 3.5", welded or bolt-in e) Landing gear: 24T, 25T
3)Chassis:
A) Provides 8 or 12 retractable type twist locks
 B) Main beam: High-tensile steel
C) Load platform: Anti-slip steel sheet floor or other materials
D) Surface preparation:Shot blast
E) Painting: Zinc-rich primer and modified urethane topcoat as customers' choices
4) Brake system:
A) Double line air brake system with single air tank, standard connectors on front bolster
B) Optional anti-lock brake system
5)Electrical system: Standard electrical equipment
6)Accessories:
A) Tool box (box only)
B) Spare wheel holder (no spare tyres and wheels).
We can design as your detail require.
