Quick Details

• Use: Other Trailers

• OEM No:cimc trailer

• Max Payload: 60T

• Size: 15150*2480*1250mm

• Place of Origin:Shandong, China (Mainland)

• Brand Name: CIMC

• Model Number: ZJV9408TJZ

• Axle: FUWA

• Material: Steel

Packaging & Delivery

Packing Details:in bulk or by containers

Delivery Detail:30 days

Steel Structure:

Material: High strength low alloy steel with (Q345) 350 MPa yield strength is used for

welded I-beam and (Q235) 235 MPa yield strength is used for the fabricated parts.

Main Beams: I-beam 550mm deep with 6mm thickness x 146mm width, top and bottom flanges are 14mm and 16mm.

OEM Parts Configuration:

King Pin: 2” bolting king pin. Brand: JOST

Landing Gear: two speed road side winding with sand shoe. Brand& type: Jost C200T

Suspension: Mechanical suspension with 8 leaf springs.

Axles: 150*150 Square axles with 13 tons capacity. Supplier: FUWA. Made in China.

Rims:9.0-22.5, 10 Holes ISO, 16pieces 1piece

Tires: 12R22.5, Radial tire, 16pieces 1piece; China Famous Brand: Double coin.

Brake System: Dual air brake system. No ABS brake system. made in china

Brake chamber: Type 30/30 on all axles.

Electrical System: 24 volt lighting system, 7-way receptacle.no e-mark and SAE Certificate.

Others:

Twist locks: equipped 8 container twist locks.

Tool box: equipped two tool boxes.

Spare Tire & Carrier: equipped 2 tire carriers with one spare tire.

Side Guard: Standard.

Painting: As customer required.

Marking: Qingdao CIMC Special Vehicle Co., Ltd.
