- Size: 12500*2500*1550
- Place of Origin: Shandong Qindao
- Brand Name: CIMC
- Model Number: QINGDAO CIMC13M flatbed semi-trailer with three axles
- Weight: 6000.000 kg
Quick Details
· Use:Other Trailers
· Max Payload:60Ton
· Size:13mX2.5mX1.59m
· Place of Origin:Shandong,China (Mainland)
· Brand Name:CIMC
· Model Number:ZJV9408LB
Packaging & Delivery
Packaging Details:By container
Specifications
1.Can be used to transport containers.
2.Can be used to transport bulk cargos.
3.Two units can be loaded into one 40'HC .
Three-axle 13m Flatbed Trailer
(Model: ZJV9408LB)
The flat top trailer is designed for use in stevedoring and transporting loose cargo.
Dimension(approximate) :
OverDimension:13,000mm(Length)×2,480±20mm(Width)×1,585mm(Height)
King Pin Location:1,350 mm from the front face of the front bolster.
Axle spacer:6,800mm 1,360mm 1,360mm
Fifth Wheel Height:1,340mm with the chassis level.
Landing Gear location:2,500mm behind the king pin location
(The above dimension will be adjusted according to the tractor specification.)
Weight:Tare weith:8440KG
Max. Payload:60,000 kg
Steel Structure:
Material:High strength low alloy steel with 350 MPa yield strength is used for welded I-beam and 235 MPa in other fabricated parts.
OEM Parts Configuration:
King Pin:3.5” exchangeable (bolted) king pin, Supplier:JOST
Landing Gear:2 speed road side winding with sand shoe, Lifting capacity 24T.Type: JOST D200T, Right operating.
Suspension:Mechanical suspension with 8 leafs spring (90mmwidth, 16mm thickness)
Axles:150x150 square axle with 15 tons capacity,Supplier & type:FUWA, Made in China.
Rims:8.5-24, 10 Holes ISO, 12 pieces. China Famous Brand.
Tires:12.00R24, Radial tyre,12 pieces; China Famous Brand.
Brake System:Wabco relay emergency valve, none ABS brake system.
Brake Chamber:30/30 type on the rear axle, 30 type on the front axle
Electrical System:Complete 24V installation with modular wiring harness. 7 pole plug placed at front in accordance to ISO, norms NO.1185.
Accessories:
Spare Tire Carrier:Equipped one set per chassis without spare tire.
Side Guard:Steel Side Protection.
Tool Box:Equipped one set.
Marking:Qingdao CIMC Special Vehicle Co., Ltd. standardTechnical data plate including chassis NO., dead weight,year of manufacturing etc.to be fitted
Painting:Color by customer’s requirement.
Water tank:200L stainless steel water tank.
Note:
1) All the details not mentioned above should comply with Chinese regulations.
2)These specifications are given as information. CIMC reserves its right to change them without previous notice.
