- Size: 12500*2500*1550
- Place of Origin: Shandong Qindao
- Brand Name: CIMC
- Model Number: CIMC Four axles flatbed trailer
- Weight: 6000.000 kg
Quick Details
Use:Truck Trailer
Max Payload:60T
Packaging & Delivery
Packing Details:By 40ft container with rear cut
Delivery Detail:30 days
The terminal chassis is designed and manufactured to transport 1x20’, 2x20’, 1x40’ ISO containers or multiple bulk cargos.
Dimension:
Overall Length:12,489 mm
Overall Height:1,530mm
Overall Width:2,480mm
King Pin Location:1,000mm from the front face of the front bolster
Landing gear position:2,420 from the king pin.
Axle spacer:Approx6, 200mm 1,310mm 1,310mm 1,310mm.
(The above dimension will be adjusted according to the tractor specification.)
Weight:
Tare Weight:8,300kg
Payload:50,000kg
Steel Structure:
Material:High strength low alloy steel with (Q345) 350 MPa yield strength is used for
welded I-beam and (Q235) 235 MPa yield strength is used for the fabricated parts
OEM Parts Configuration:
King Pin:3.5” olting king pin. Brand: JOST
Landing Gear:two speed road side winding with sand shoe.
Brand & type:Jost C200
Suspension:Mechanical suspension with 8 leaf springs.
Axles:150*150 Square axles with13 tons capacity
Supplier:FUWA OR BPW Made in China.
Rims:9.0-22.5,10 Holes ISO,16pieces 1piece
Tires:315/80R22.5,Radial tire,16pieces 1piece; China Famous Brand: Triangle.
Brake System:Dual air brake system. ABS brake system. made in china
Brake chamber:Type 30/30 on the rear two axles, Type 30 on the front two axles.
Electrical System:24 volt lighting system, 7-way receptacle.no e-mark and SAE Certificate.
Others:
Twist locks:equipped 12 container twist locks.
Tool box: equipped one tool box
Spare Tire & Carrier: equipped 2 tire carriers with one spare tire.
Side Guard:Standard.Front Fender:1 meter high.
Painting:Yellow.Marking: Qingdao CIMC Special Vehicle Co., Ltd.
NOTE
1.All The details not mentioned above should be comply with Chinese standard.
2.These specifications are given as information. CIMC Qingdao have the right to change them without previous notice.
