- Size: 13000*3000*3180 mm
- Place of Origin: SHANDONG
- Brand Name: CIMC
- Model Number: 3 axles 60 tons Low bed semi trailer
- Weight: 6000.000 kg
Product Description
√ High tensile strength steel Q345A for I-beam
√ Axle: FUWA or BPW Brand
√ Suspension: Mechanical suspension or Air suspension
√ Kingpin: JOST 2’’or 3.5” optional
√ C/O FORM E,CNCA,CQC,BV,CIQ, SASO,GOST,SGS, SUNCAP, FERI, EMBASSY CERTIFICATION.etc.
√ Long-time cooperation with the large shipping companies, supply faster delivery for our customers.
PARAMETER | Dimension(mm) | L*W*H: 1 3 000 X 3000 X 3180 (MM) |
Kin Pin Plate Height (mm) | H | |
Axle space(mm) | 8715 1310 1310( mm ) | |
Tare weight( kg ) | 1 2 000 KGS | |
Payload (kg ) | 5 0000KGS | |
G.V.W.R. | 62 000KGS | |
“ I ” BEAM | 550/25/30/14 | |
OEM | Landing gear | Two speed manual operation type with sand shoe |
Kingpin | 3.5 ” Bolted type | |
Brake system | Dual line pneumatic brake system. WABCO brake valve | |
A BS | No | |
Brake chamber | Type 30/30 spring brake chamber | |
Suspension | Spring suspension | |
Axle | FUWA square axle, 13 ton capacity/set ,3pcs | |
Tire | 8.25 R20 12 Pcs | |
Rim | 6.5R -20 12 Pcs | |
Tool box | 1( 1M ) | |
Spare tire carrier | 2 Units | |
OTHERS | Floor | 4 mm checke d plate |
Painting | As customer request |
